MSI MAG A1000G PCIE 5 80 Plus Gold Modular Power Supply | 306-7ZP7C18-CE0

Brands:
Availability: Out of Stock
  • 1000W Single +12V Rail
  • 135mm Cooling Fan
  • Intel ATX12V Version 3.0
  • 1 x 16-Pin Connector

  • Free delivery over 200
  • 7 Days Return Period
  • Customer support+971502525069

Guarantee Safe & Secure Checkout

Categories: , Tags: , Brands:

Description

Balancing power, safety, and efficiency, MSI MAG A1000G PCIE 5 80 Plus Gold Modular Power Supply | 306-7ZP7C18-CE0 offers robust flexibility for users looking to leverage NVIDIA’s GeForce RTX 40 Series graphics cards and other resource-demanding components. Giving you up to 1000W of power and sporting the ATX 3.0 electrical design, it accommodates a wide range of components with ease.

A dedicated 16-Pin PCIe 5.0 connector supports NVIDIA’s GeForce RTX 40 series graphics cards which sport a unique connector. The power supply’s modular form factor and sleeved cables let you pick and choose which cables you need for your rig, saving room and streamlining your wire management step. The 80 PLUS Gold efficiency rating ensures optimal power throughput, giving you up to 90% efficiency at half power loads.

80 PLUS GOLD Certified
The efficiency of your power supply directly influences your system’s performance and power consumption. The 80 PLUS Gold certification promises lower energy consumption and higher efficiency.
Safety and Stability
105°C Japanese capacitors enhance electrical throughput and add a layer of reliability and durability to the PSU. You also get several electrical protections including OCP, OTP, OVP, OPP, UVP, and SCP.
Fan Cooling
A hydro-dynamic bearing fan concentrates the airflow, optimizing cooling capabilities with a liquid crystal polymer fan blade design.
Designed to Deliver
  • The MPG A1000G PCIE’s single +12V rail provides ample power for high-performance graphics cards and CPUs
  • Active Power Factor Correction (PFC) ensures optimal efficiency
  • A 135mm fan with a Fluid Dynamic Bearing design provides ample cooling
  • Use the 0 RPM fan mode to stop the fan from spinning when the TDP is below 40%, allowing you to enjoy games in peace
  • Measuring just 5.9″ on its longest side, the MPG A1000G PCIE5 features a compact design for versatile deployment in a range of cases
Use What You Need
The MPG A1000G PCIE5’s fully modular design means that only the connectors required by the build need to be used, significantly reducing cable clutter and allowing for a clean build.



Specifications

Total Connectors1 x 24-Pin ATX Motherboard, 2 x 4+4-Pin EPS CPU, 1 x 16-Pin PCIe (12VHPWR), 6 x 6+2-Pin PCIe, 12 x 15-Pin SATA, 4 x 4-Pin Peripheral / Molex, 1 x 4-Pin Floppy
Cable DesignModular
PCIe Connector Distances23.6″ / 600 mm
SATA Connector Distances19.7″ / 500 mm, 5.9″ / 150 mm
Peripheral Connector Distances19.7″ / 500 mm, 5.9″ / 150 mm
Floppy Connector Distances5.9″ / 150 mm
ATX Connector Distance23.6″ / 600 mm
EPS Connector Distances27.6″ / 700 mm
Electrical
Total Wattage1000 W
Number of +12 V Rails1
Combined Power for +12 V1000 W
Max Load for +12 V83.5 A
Combined Power for +3.3/+5 V120 W
Max Load for +3.3 V22 A
Max Load for +5 V22 A
Max Power for +5 Vsb15 W
Max Load for +5 Vsb3 A
Max Power for -12 V3.6 W
Max Load for -12 V0.3 A
Peak Power1000 W
AC Input Power100 to 240 VAC, 50 / 60 Hz at 5 to 10 A
General
Efficiency Rating80 PLUS Gold
Active Power Factor CorrectionYes
Efficiency90%
Cooling
Fan Size135 mm
Bearing TypeFluid Dynamic Bearings (FDB)
Physical
Form FactorATX
ProtectionOver-Current Protection, Over-Power Protection, Over-Temperature Protection, Over-Voltage Protection, Short-Circuit Protection, Under-Voltage Protection
Dimensions5.9 x 3.4 x 5.9″ / 150 x 86 x 150 mm
Weight7.6 lb / 3.4 kg
Packaging Info
Package Weight7.71 lb
Box Dimensions (LxWxH)11.8 x 9.9 x 5.5″
BrandMSI
Weight4.500000
